Yamaha All New R15 Spesifikasi

825 Views

Yamaha All New R15

Mesin

TIPE MESIN Liquid Cooled 4-Stroke, SOHC, 4 Valve, VVA
Volume Cylinder 155.1cc
JUMLAH / POSISI SILINDER Single cylinder
DIAMETER X LANGKAH 58,0 x 58,7 mm
PERBANDINGAN KOMPRESI 11.6 ± 0.4 : 1
DAYA MAKSIMUM 14,2 kW/10000rpm
TORSI MAKSIMUM 14,7 Nm/8500rpm
SISTEM STARTER Electric starter
SISTEM PELUMASAN Wet sump
KAPASITAS OLI MESIN Total =1.05L ;Berkala = 0.85 L ;Ganti Filter Oli = 0.95 L
SISTEM BAHAN BAKAR Fuel Injection
TIPE KOPLING Wet Type Multi-Plate Clutch; Assist & Slipper Clutch
TIPE TRANSMISI Manual

Dimensi

P X L X T 1990mm X 725mm X 1135mm
JARAK TERENDAH KE TANAH 155mm
TINGGI TEMPAT DUDUK 815 mm
BERAT ISI 137 kg
KAPASITAS TANGKI BENSIN 11L
JARAK SUMBU RODA 1325mm

Rangka

TIPE RANGKA Deltabox
SUSPENSI DEPAN Teleskopic Fork (Inverted)
SUSPENSI BELAKANG Link Monoshock
BAN DEPAN 100/80-17M/C 52P
BAN BELAKANG 140/70-17M/C 66S
REM DEPAN Disc brake
REM BELAKANG Disc brake

Kelistrikan

SISTEM PENGAPIAN TCI
BATTERY GTZ4V/YTZ4V
TIPE BUSI NGK/MR8E9
